⚠️NOTE⚠️
✉ BARANG DENGAN BERAT 50kg KE ATAS AKAN KAMI BANTU KIRIM DENGAN EKSPEDISI SESUAI REQUEST atau BISA AMBIL DI TEMPAT KAMI
✉ Kita kirimkan invoice terlebih dahulu
✉ Lama pengiriman 1-2hari kerja
✉ Jika ada komplain, langsung hubungi admin kami (09.00-17.00).
🚫Komplain/reputasi buruk sebelum berkomunikasi akan menghambat proses klaim dan transaksi dianggap selesai.
MODEL : 2CDXM 70/10
POWER : 1HP / 0,75KW
VOLTAGE : 380VOLT
BRAND : EBARA
TERJAMIN KEASLIAN 100%
APPLICATIONS
• Domestic pressure boosting
• Small-scale garden irrigation
• Micro Brewing
• Washing
• Treating water
• Cooling towers
• Moving clean water in general
TECHNICAL DETAILS
• Strong structure
• Small dimensions
PUMP TECHNICAL DATA
• Maximum working pressure: 8 bar
• Maximum temperature of the liquid:
-5°C ÷ +60°C for standard and E version
-5°C ÷ +110° for H-HS-HW-HSW version
• G1½ suction connection for 2CDX 200, G1¼; for the rest of the range
• G1 discharge connection
MOTOR TECHNICAL DATA
• High efficiency motors IE2 starting from 0,75kW
• Self-ventilated 2 pole asynchronous motor
• Class of insulation F
• IP55 Protection degree
• 230V ±10%, 50Hz single phase voltage
230/400V ±10%, 50Hz three phase voltage
• Permanent capacitor inserted and thermo-amperometric protection
with automatic rearm incorporated for the single phase motor
• Protection under user's responsibility for the three phase version
